Data Structures Lesson 3: LinkedLists
OPTIONAL: Java Crash Course Video
This video is optional, but maybe those of you who are having trouble getting reacquainted with Java should watch it.
I cover a lot of things in this video, hoping that by going through an example of a simple class or two, I can illustrate some of the subtle issues that can creep up from time to time. Things that I covered here include:
- Classes: representing “state” (or “data”) and “behavior”.
- Object oriented programming: modeling your code around the “things” in your program, rather than the “actions” your program needs to do.
- Interfaces, classes, run-time types vs compile-time types
I don’t cover inheritance, which may be an important notion, but I do not expect that we will be using it in this class.
LinkedLists
A LinkedList is another implementation of the List abstract data type. In this implementation, instead of storing all of the data in contiguous memory cells (as in arrays), we store each data element in its own “Node”, which also keeps track of where the “next” element in the list is.
From the code, you can see that there are not too many steps to add a new element to the end of a list, or to the beginning of the list. Please take a look at the code, and try to analyze the running times for each of the operations (add, addFirst, get, removeElementAtPosition, insert).
Now that said, some of these “efficient” operations are somewhat theoretical. Here is some light reading on that fact.
Stacks and Queues
Next we will examine two important ADTs: stacks and queues.
Stack:
Queue:
Both of these ADTs specify two operations: insertion and removal. Most implementations also specify a “peek” in addition to a “remove”, as well as a “size” and/or “isEmpty” operation.
The operations on a stack are called push and pop. push adds an item “on top” of the stack, and pop removes the top item of the stack. Stacks use the LIFO, or “Last In, First Out,” paradigm: the last object added to the stack is the first one to be taken out.
The operations on a queue are called enqueue. enqueue adds an element to the “end” of the queue, while dequeue removes an element from the beginning of the queue. That is, queues use the FIFO paradigm: the first object added to the queue will be the first one removed.
Some questions to think about:
- How might you implement each of these ADTs with an array / ArrayList?
- How might you implement each of these ADTs with a LinkedList?
See if you can come up with implementations in which all the operations listed above are $O(1)$.
Warning: never use the built-in java.util.Stack class. There are better implementations: in particular, ArrayDeque and LinkedList.
Deques
There is a related ADT called a deque, or a doubly-ended queue. This would support all of the operations: push / pop and enqueue / dequeue. In Java, Deque is an interface (as is Queue), with implementations ArrayDeque and LinkedList. The actual methods are listed on the API linked earlier.
Challenge Questions
Some problems to think about. Try to find the best algorithms to solve these problems. I don’t expect you to do all of these, or even to implement any of them, but do your best to come up with an algorithm that would solve it (at least on paper). Then we can discuss some of our solutions on Monday.
Reverse a Singly Linked List
Given a singly LinkedList, how might you implement a reverse method? Moreover, how might you do this in-place: that is, without using a secondary list or additional storage?
Middle element of a Linked List
Given a singly LinkedList, how might you find the middle element in one loop? (ie in N steps, not in 2N steps).
Collate Iterators
Suppose we have an array of Iterators. Implement an Iterator which “collates” these. That is, suppose we have iterators for the following lists:
- [0, 1, 2]
- [3, 4 ]
- [5, 6, 7, 8, 9]
Then the result of
Iterator<Integer> iter = new CollatedIterator(iterArray);
while (iter.hasNext()) {
int i = iter.next();
System.out.println(i);
}
would be 0, 3, 5, 1, 4, 6, 2, 7, 8, 9 (on separate lines, without commas).
Bracket Matching
The following strings of brackets are perfectly matched:
- {}([])
- [(()())]
The following are not:
- {(})
- (][)
Devise an algorithm which, given a string of brackets, determines if the brackets are perfectly matched.
Base Counting
Devise an algorithm which, given an input $n$, outputs all numbers from 1 to $n$ in binary. Example: if $n = 5$, then we write 1, 10, 11, 100, 101, 110. (The format of the output doesn’t matter, they can all be on separate lines.)
